Loading Spout Positioners

Process Solutions is the Official Representative of DCL in North and South Carolina

SmartLoader-​ Features a patented vision system that scans the top of the vehicle. It automatically locates, measures and qualifies any open hatch or series of hatches. The multi-speed positioner provides a fast scanning speed to minimize loading cycle times. A unique positioning arm is used to move the loading spout within a designed loading area. The Smart Loader can cover an area of 60 feet by 6 feet (360 sq ft).

More Information on options specific to your needs is available here

Articulating Positioning Arm- Designed to decrease loading times, the Articulating Positioning Arm can move 60 feet by 6 feet, giving a total loading area of 360 sq ft. Conveying arms can be provided as aeration conveyor, en masse and screw conveyor configurations.

More Information on options specific to your needs is available here

Dual Direction Loading Spout Positioner- Dual direction positioners move standard duty loading spouts horizontally in the X and Y axes to load trucks or railcars. Can move 6 feet by 2 feet (12 sq feet).

More Information on options specific to your needs is available here

Rotary Loading Spout Positioner- Rotary positioners are used to move standard duty loading spouts horizontally in a radial axis when loading trucks or railcars. Range from covering a 4 foot diameter area to a 12 foot diameter area.

More Information on options specific to your needs is available here

Single Direction Loading Spout Positioner- Single direction positioners move standard duty loading spouts horizontally in the X axis to load trucks or railcars. Has a range of 2 to 6 feet.

More Information on options specific to your needs is available here
